Alfa

Alfa COB
Alfa COB
Alfa COB

Specifications & Features

  • Die cast Aluminum housing with toughened glass cover concealed with high temp resistance silicon rubber gasket
  • 60% energy saving Vis a Vis Conventional HID Flood light
  • Over load, over voltage & short circuit protection
  • Isolated constant current driver with PF > 95%
  • More than 85% driver efficiency with < 10% Current THD
  • Equipped with 5KV Surge suppression Protection
  • Wide operating voltage 100 - 285V
  • Color Rendering Index (CRI) > 80
  • Working ambient temperature -20°C to + 50°C
  • Rated Life 50,000Hrs (Ta= 30°C @ L70)
  • High intensity of illumination with 120°view angle
  • Frosted glass cover to control glare
  • Flicker free instant start electronic operation
  • Electric wave & radio interference free
  • Without mercury, UV & IR radiation
  • Class I Electric Strength.
  • IP 65 Ingress Protection

    • Applications

  • Building Facade
  • Landscape
  • Hotel
  • Parks
  • Monuments
  • Shopping mall
  • Museum & art galleries

    • Installation & Maintenance

  • Mounted with bracket /cradle on any rigid surface
  • Power Supply should be disconnected before service

    • Technical & Ordering Information

    Product ID / Ordering Code Product Description Wattage(W) Nominal Voltage(V) Mains Current(A) CCT (K) Lumen (lm)
    VL/FDL-602-LED01065 Alfa LED Flood Light COB 10/CW IP 65 10 230 0.045 6500 900
    VL/FDL-602-LED02065 Alfa LED Flood Light COB 20/CW IP 65 20 230 0.090 6500 1800
    VL/FDL-602-LED03065 Alfa LED Flood Light COB 30/CW IP 65 30 230 0.135 6500 2700
    VL/FDL-602-LED030RGB Alfa LED Flood Light COB 30/RGB IP 65 30 230 0.135 RGB ---
    Lamp Enclosed Rated

    * xx also available in 3000K CCT on request.
