VLI LED EXTRUDATE SERIES

PDF Version

High-Performance Sports & Flood Lighting Solutions

Product Overview

The VLI LED EXTRUDATE SERIES features a stretching aluminium light combination design with simple and beautiful appearance. Engineered with strong heat dissipation capabilities and convenient installation, this series offers optimal performance for demanding sports and flood lighting applications. All adopt superior stainless steel nuts. Using efficient&reliable driver to improve Stability and lifespan. High-strength mounting bracket to meet Security performance requires. Special beveling design could avoid light Pollution.

Applications

Gymnasiums and sports halls
Golf courses and driving ranges
Airport warehouses and hangars
Wharfs and port facilities
Large building squares
Stadiums and arenas
Industrial complexes
Outdoor sports facilities

Technical Features

Extruded aluminum shell for perfect heat dissipation
High-class LED chip 5050 (15°-90° beam angles)
All stainless steel nuts for corrosion resistance
Efficient & reliable driver for stability
High-strength mounting bracket for security
Special beveling design to avoid light pollution

Product Benefits

Long Lifespan : Perfect protective performance even in wet environments
Flexible Application : Wide range from different luminous efficiency to installation sites
Easy Maintenance : Modular structure allows quick replacement and servicing
Energy Efficient : High lumen output with optimal power consumption
Customizable : Multiple configurations to meet specific customer requirements

Technical Specifications

Item description	LED760WFC 200W	LED760WFC 250W	LED760WFC 300W	LED760WFC 340W	LED760WFC 400W	LED760WFC 500W	LED760WFC 600W	LED760WFC 700W	LED760WFC 800W	LED760WFC 1000W	LED760WFC 1200W	LED760WFC 1500W
Input voltage [VAC]	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC	100-277 VAC
Input frequency [Hz]	50/60	50/60	50/60	50/60	50/60	50/60	50/60	50/60	50/60	50/60	50/60	50/60
Input current (200V) [A]	0.9	1.13	1.36	1.55	1.81	2.27	2.72	3.18	3.63	4.54	5.45	6.61
Input Watt [W]	200±5%	250±5%	300±5%	340±5%	400±5%	500±5%	600±5%	700±5%	800±5%	1000±5%	1200±5%	1500±5%
Power factor	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95
Current (reference) [A]	3.47	4.33	5.19	5.89	6.93	8.66	10.39	12.12	13.86	17.32	20.8	26
Power Efficiency	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%	≥93.5%
Luminous flux [Lm]	35000	42500	48000	54400	70000	85000	96000	119000	132000	160000	192000	240000
Color temperature [K]	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K
Color rendering index [Ra]	≥70	≥70	≥70	≥70	≥70	≥70	≥70	≥70	≥70	≥70	≥70	≥70
Beam angle [H, V]	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°	15° 30° 45° 60° 90°
LED Type	5050	5050	5050	5050	5050	5050	5050	5050	5050	5050	5050	5050
IK Rating	IK08	IK08	IK08	IK08	IK08	IK08	IK08	IK08	IK08	IK08	IK08	IK08
Average life [h]	54000	54000	54000	54000	54000	54000	54000	54000	54000	54000	54000	54000
Net weight [Kg]	5.7	5.7	6.3	6.3	11.3	11.3	11.6	19.5	20	20.3	26.6	30.7
Gross weight [Kg]	6.6	6.6	7.13	7.13	13.58	13.58	13.84	23.2	23.5	24	31	36.5
Dimensions [mm]	570235180	570235180	570235180	570235180	590375185	590375185	590375185	605560235	605560235	605560235	725605225	890605235
