VACADEMY SERIES
Ultra-Thin Premium LED Luminaires
Product Overview
The VACADEMY series of luminaires are ultra-thin and lightweight, designed to deliver premium performance and perfect uniformity of light without glare. Combining a minimalistic and aesthetically appealing approach with the low energy, low maintenance benefits of LED lighting technology.
Design Excellence
VACADEMY offers the ideal solution for interior lighting applications where both performance and aesthetics matter. The series combines sleek, modern design with advanced LED technology to provide glare-free, uniform illumination perfect for educational, commercial, and institutional environments.
Applications
Technical Specifications
| Part Code | Lumens | LPW | Rated Life (Hrs) | L70 B50 @ 25°C (Hrs) | CCT (K) | CRI (Ra) | Beam (°) |
|---|---|---|---|---|---|---|---|
| COM003 | 2,400 | 104 | 50,000 | >50,000 | 4000 | >80 | 120 |
| COM004 | 4,000 | 108 | 50,000 | >50,000 | 4000 | >80 | 120 |
| COM005 | 4,640 | 108 | 50,000 | >50,000 | 4000 | >80 | 120 |
| COM006 | 6,150 | 102 | 50,000 | >50,000 | 4000 | >80 | 120 |
Environmental & Safety Specifications
Environmental Data
- Max. Ambient: 45°C
- Min. Ambient: -20°C
- IP Rating: IP40
Safety Data
- Short Circuit Protection: Yes
- Over Volt Protection: Yes
General Data
- ECA Compliant: Yes
- Energy Rating: A+
- SDCM: <6
Performance Benefits
Light Quality
- 4000K CCT - Perfect neutral white for educational environments
- CRI >80 - Excellent color rendering for accurate visual tasks
- 120° Beam Angle - Wide, uniform light distribution
- SDCM <6 - Minimal color variation between units
Efficiency & Reliability
- 104-108 LPW - High luminous efficacy
- 50,000+ Hours - Long operational life
- Energy Rating A+ - Top energy efficiency class
- L70 B50 >50,000 hrs - Maintains 70% output after 50,000 hours
Model Comparison & Applications
| Model | Light Output | Efficacy | Typical Applications | Coverage Area |
|---|---|---|---|---|
| COM003 (2,400 lm) | 2,400 lumens | 104 LPW | Small classrooms, offices, corridors | Up to 15m² |
| COM004 (4,000 lm) | 4,000 lumens | 108 LPW | Medium classrooms, meeting rooms | 15-25m² |
| COM005 (4,640 lm) | 4,640 lumens | 108 LPW | Large classrooms, open plan offices | 25-35m² |
| COM006 (6,150 lm) | 6,150 lumens | 102 LPW | Auditoriums, libraries, large spaces | 35-50m² |
Design Advantages
Energy Efficiency
With efficacy ratings up to 108 LPW and A+ energy rating, VACADEMY luminaires significantly reduce energy consumption while maintaining premium light quality.
Visual Comfort
Designed specifically to eliminate glare and provide perfect uniformity, ensuring optimal visual comfort for extended periods in educational and work environments.
Aesthetic Appeal
Ultra-thin, lightweight design with minimalistic aesthetics complements modern architectural designs while providing superior lighting performance.
Easy Maintenance
50,000+ hour lifespan and robust construction ensure minimal maintenance requirements, reducing total cost of ownership.
